High quality lever limit switch

◎ Open capacity up to 15A, and high repetition accuracy. ◎ Transmission forms are extremely rich, can be customized according to user requirements of special specifications. ◎ There are also small load series and drip proof series in the standard type. ◎ In order to protect the safety of the terminal part, it is equipped with a variety of terminal protective covers, and can also choose a drip proof terminal type product.

Product Details

◆ Operating characteristics
1. Action force (OF) ≤0.69N (70gf)
2. Reset force (RF) ≥0.14N (14gf)
3. Free position (FP) ≤28.2mm
4. Overshoot (OT) ≥5.6mm
5. Difference (MD) ≤1.3mm
6. Operation position (OP) : 19±0.8mm

◆ Performance Characteristics
1. Allowed frequency:
Mechanical: 240 cycles/min
Electrical performance: 20 times/min
2. Insulation resistance: more than 100mΩ (DC500V megohm meter)
3. Contact resistance (initial value) : ≤15mΩ
4. Breakdown resistance voltage:
Between non-connected terminals: AC1000V, 50/60HZ, 1 minute
Between metal parts and terminals: AC2000V, 50/60HZ, 1 minute
Between ground and terminal: AC2000V, 50/60HZ, 1 minute
5. Impact resistance: ≤50m/s²
6. Life: mechanical life more than 5 million times, electrical life more than 500,000 times
7. Ambient temperature and humidity: -25℃ -+ 80℃, below 85%RH

◆ Use environment
◎ Do not use in direct contact with various organic solvents, strong acids, strong alkaline liquids and steam, or in the environment with flammable gases and corrosive gases.
◎ Please use in the ambient temperature range of -25℃~+80℃. (Please do not condense or freeze)
◎ In order to improve the reliability of actual use, please try to confirm the quality requirements under actual use conditions.
◎ Do not use in air containing silicon. (For example, in the case of silicification of silicone series rubber, adhesive, sealant, oil, lubricating oil or wire)
◎ Avoid use in dusty environments, it will hinder the action of the actuator.
◎ Avoid use in outdoor (three-dimensional parking lot, long-term sunlight or places that may be soaked in rain) or in an environment that produces ozone, which will cause deterioration of rubber materials.
